SMT Laser PCB Cutting Machine FR4 With Solid State UV Laser

SMT Laser PCB Cutting Machine FR4 With Solid State UV Laser
SMT Laser PCB Cutting Machine FR4 With Solid State UV Laser
SMT Laser PCB Cutting Machine FR4 With Solid State UV Laser SMT Laser PCB Cutting Machine FR4 With Solid State UV Laser SMT Laser PCB Cutting Machine FR4 With Solid State UV Laser

Large Image :  SMT Laser PCB Cutting Machine FR4 With Solid State UV Laser

Product Details:
Place of Origin: China
Brand Name: Winsmart
Certification: CE
Model Number: SMTL600
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD1-150K/set
Packaging Details: Plywood case
Delivery Time: 5-30 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100 sets per month

SMT Laser PCB Cutting Machine FR4 With Solid State UV Laser

Description
Color: White Working Area: 600x600mm
Scan Range: 40x40mm Fixture: 1
Laser: Solid-state UV Laser Name: PCB Laser Cutter
High Light:

FR4 Laser PCB Cutting Machine

,

SMT Laser PCB Cutting Machine

,

355nm PCB Laser Cutting Machine

SMT Laser PCB Cutting Machine for FR4 PCB Boards PCB Separator



Laser PCB Cutting Machine Advantages:

1. The laser process is completely software-controlled. Varying materials or cutting contours are easily taken into account by adapting the processing parameters and laser paths. There is also no need to factor in retooling times during a change of production.

2. No appreciable mechanical or thermal stresses occur. The ablation products are extracted by suction directly at the cutting channel. Even sensitive substrates can thus be precisely processed.

3. The laser beam merely requires a few µm as a cutting channel. More components can thus be placed on a panel.

The system software differentiates between production and set up processes which drastically reduces instances of faulty operation.



Laser PCB Cutting Machine Features:

1. No mechanical stress

2. Lower tooling costs

3. Higher quality of cuts

4. No consumables

5. Simple software changes enable application changes

6. Works with any surface—Teflon, ceramic, aluminum, brass and copper



Laser PCB Cutting Machine Specification:



Laser Q-Switched diode-pumped all solid-state UV laser
Laser Wavelength 355nm
Laser Source Optowave UV 15W@30KHz
Positioning Precision of Worktable of Linear Motor ±2μm
Repetition Precision of Worktable of Linear Motor ±1μm
Effective Working Field 600mmx600mm(Customizable)
Scanning Speed 2500mm/s (max)
Working field 40mmх40mm





Laser PCB Cutting Machine Workshop:

SMT Laser PCB Cutting Machine FR4 With Solid State UV Laser 0



Our Advantages:

Our machine is completed with fine finishing in accordance with the quality standards of the industry.
Our strict quality management system maintains the excellent performance and quality of our products.
The product is the preferred one in the fields for its huge economic benefits.



Our Service:

1. Lifetime technical support and 2 years warranty.
2. Free replacement or refund would be done in case of any quality problem.
3. Fast response/feedback within 12 hours
4. Engineers are available to be sent to do oversea installation and training.
5. Solid packaging to prevent damage from transportation.



Shipment:

1. DHL/FedEx/UPS/TNT Express

2. Air

3. Railway

4. Ocean

5. Truck
