MCPCB PCB V Grooving Machine , Lower Stress PCB V Cutter

MCPCB PCB V Grooving Machine , Lower Stress PCB V Cutter
MCPCB PCB V Grooving Machine , Lower Stress PCB V Cutter
MCPCB PCB V Grooving Machine , Lower Stress PCB V Cutter MCPCB PCB V Grooving Machine , Lower Stress PCB V Cutter MCPCB PCB V Grooving Machine , Lower Stress PCB V Cutter

Large Image :  MCPCB PCB V Grooving Machine , Lower Stress PCB V Cutter

Product Details:
Place of Origin: China
Brand Name: Winsmart
Certification: CE
Model Number: SMTPD2
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD1-10000/set
Packaging Details: Plywood case
Delivery Time: 2-5 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 200 sets per month

MCPCB PCB V Grooving Machine , Lower Stress PCB V Cutter

Description
Color: White PCB Material: FR1, FR4, CEM1, CEM3, MCPCB
PCB Thickness: 0.4-5mm Cutting Length: 200/330/400/580mm
Blade Type: Linear Blade Warranty: 2 Years
Condition: New Name: V Cut PCB Depaneling Machine
High Light:

MCPCB PCB V Grooving Machine

,

CEM PCB V Cutter

,

Lower Stress PCB V Cutter

V Cut PCB Depaneling Machine With Two Linear Blades Lower Stress



Features:

Pneumatic driven, electric hybrid design, double straight knife cutting, sutiable for dividing precision SMD sheet, aluminum circuit board.

Suitable for all thickness PCB, cutting board stroke is less than 2mm, no operational safety concerns.

Reduce the internal stress generated when cutting the board to below 180μST to avoid tin cracking and prevent damage to precision parts.

Cut the edge of the V groove and the width of the part is 0.3mm, the height is 50mm.

Blades can be re-sharpened

Cutting stress is less than 500 uE.



Specification:

Model SMTPD2
Machine Dimension 720x300x440mm / 520x300x440mm / 500x300x440mm
Max Cutting Length 330mm / 200mm / 130mm
PCB Material FR4, MCPCB, CEM, Copper Boards
Air Pressure 0.4-0.7MPa
PCB Thickness 0.3-3.5mm
Power 110/220V
Machine Weight 130kgs / 100kgs / 80kgs





Packaging:

MCPCB PCB V Grooving Machine , Lower Stress PCB V Cutter 0



Application:

MCPCB PCB V Grooving Machine , Lower Stress PCB V Cutter 1
