Product Details:
|
Color: | White | PCB Material: | FR4, Aluminum |
---|---|---|---|
PCB Thickness: | 0.8-3.0mm | Application: | Tab PCBA Panel |
Cutting Precision: | ±0.05mm | Max PCB Size: | 280x320mm |
Feature: | Top Cutting | Vacuum Cleaner: | Top/bottom |
Routing Bit: | Dia 0.8-2.5mm | User Manual: | 1pc |
Warranty: | 2 Years | On-site Installation: | Yes |
Product Name: | PCB Depaneling Router | ||
Highlight: | PCBA PCB Depaneling Router Machine,F 1.2.88 version PCB Depaneling Router Machine,Two Sliding Table PCB Cutting Machine |
PCB Depaneling Router Machine PCB Separator Router Machine For Aluminum PCBA
PCB Depaneling Router Features:
1. 1.X10 zoom-in image makes programming easier&increase the accuracy of point setting.
2. Two sliding table provides simultaneously in-and-out movement to reduce the tack time for better productivity.
3. AUTO MARK offset system.CCD image could check&simulate the path or routing to reduce unnecessary mistake before cutting.
4. Has routing bit life time checking and alarm system to remind operator to change routing bits when it finish 120M cutting. And routing bit first 2mm cut the first milling point, middle 2mm cut the second milling point, the last 2mm cut the third milling point to increase its life time.
5. CCD image could check & simulate the path or routing to reduce unnecessary mistake before cutting.
PCB Depaneling Router Specifications:
I. Hardware | |
SPINDLE | SycoTec(KAVO) 4025HY |
CCD | Sony 520 line industrial cameras |
LENS | Computar EX2C |
Screw | TBI Precision ground ball screw imports |
Guide | HIWIN widening Imported linear guide rail |
MOTOR | Panasonic |
I/O CONTRONL CARD | HFC PCI-9074 |
DRIVER CONTRONL CARD | HFC PCI-9074 |
I/O CARD | PCI-9074-64pcs/-38pcs |
Static cleanup | STATIC-ST401A Series |
Computer | (RMC-8401/6113LP4/300ATX/8651VNA/P4 2.8G 2CPU(S)/1G DDR/80G) |
Machine interface | AOC LCD17",Logitech mouse |
2. software | |
Control system | Windows XP Professional (Service3,v.3244) |
Operation GUI | English Windows XP |
Program edit | Inline |
Vision system | CCD AOTU offset |
Control system | F 1.2.88 version |
PCB Depaneling Router Other Models:
PCB Depaneling Router Details:
PCB Depaneling Router FAQ:
1.A: What is life time of routing bit?
Q:150-300 meters.
2.A: Can this model cut Aluminum PCB boards?
Q: Yes, it can.
3.A: What about PCB positioning?
Q: Use customized jig for positioning.
4.A:What is the spindle for the inline PCB router?
Q:Germany SycoTec 4025.
5.A:How to package it?
Q:Router and cleaner is packaged into separated wooden case after vacuum.
6.A:Is on-site installation and training available.
Q:Yes, it is available.
7.A:What is your terms of delivery?
Q:We accept ex-work, FOB, CIF, DDU, DDP, etc.
PCB Depaneling Router Packaging:
Our Service:
1. Lifetime technical support and 2 years warranty.
2. Free replacement or refund would be done in case of any quality problem.
3. Fast response/feedback within 12 hours
4. Engineers are available to be sent to do oversea installation and training.
5. Solid packaging to prevent damage from transportation.
