Product Details:
|
| Color: | White | PCB Material: | FR4, Aluminum |
|---|---|---|---|
| PCB Thickness: | 0.8-3.0mm | Advantage: | Dual Tables |
| Cutting Precision: | ±0.05mm | Max PCB Size: | 320x320mm |
| Feature: | Top Cutting | Cutting Speed: | 1-100mm/s |
| Cleaner: | Optional Top And Bottom Vacuum System | Product Name: | PCB Depaneling Router Machine |
| High Light: | 6KG/Cm2 PCB Depaneling Router Machine,FR4 PCB Depaneling Router,CCD PCB Board Cutting Machine |
||
6KG/Cm2 Air Visual CCD System Top Vacuum Cleaner PCB Depaneling Router
The PCB Depaneling Router is an advanced machine designed for precise and efficient PCB depaneling. It incorporates a visual CCD (Charge-Coupled Device) system for accurate alignment and a top vacuum cleaning mechanism for debris removal. This machine ensures high-quality cuts and maintains cleanliness during the depaneling process, making it suitable for demanding PCB manufacturing environments.
PCB Depaneling Router Features:
PCB Depaneling Router Specifications:
| Overall | |
| Dimensions(W*D*H) | 1250mm*1650mm*1450mm |
| Weight | 750KG |
| Height offset | 60~110mm |
| Manipulator | |
| Motor type | JiaBao series |
| Positioning repeatability | 0.001mm |
| Axis working area(max) | 650mm*560mm*50mm |
| Work station | |
| PCB fixation | standard,specialization |
| PCB loading/unloading | manual |
| PCB size (max) | 320*320mm |
| PCB thick (max) | 5mm |
| Fixturing | |
| Rigidity fixturing | Customized make fixture |
| Fixturing fixation | machinery |
| Spindle Motor | |
| Power | 150W |
| Spindle | 60000rpm/min |
| Protect | self/wind cooling |
| Change cutter | Specialization |
| Routing capability | |
| Cutting speed(max.) | 80mm/s |
| Driving speed(max.) | 2500mm/s |
| Precision of cutting | 0.01mm |
| Vacuum System | |
| Vacuum power | 3.5KW AC 380V |
| Vacuum | plumb |
| Utilities | |
| Power | 2.0KW AC380V |
| Air supply | 4-6KG/cm2 |
| Programming | |
| Program edit | Inline |
| Function edit | Line,arc,circula,U-curve |
| Program storage | HDD |
| Vision system | SONE colour CCD |
| milling cutter offset | AUTO |
| Vacuum setup | AUTO |
| Operation Monitors | |
| Iindicator | Iindicator Machine state |
| tool check | Automatic detection tool life, the use of time testing |
| Motor protect | Have overheating, overload, low voltage protection function |
| motor over loading check | Have Overload, the line is normal, low voltage protection function |
| Tool usable time | Automatic detection tool life, |
| Data statistic | Separate board model, separating count, diverse counting methods |
| Error record | Software automatically records all alarms memory of machines |
| III. Accuracy | |
| Axis precision | 0.001mm |
| Cutting precision | 0.1mm |
| IV. Safety | |
| Working area protect | With four sealed protection |
| Door sensor | Front and rear safety door micro-switch sensor (optional) |
| Exigency stop button |
PCB Depaneling Router Details:
PCB Depaneling Router Applications:
The Visual CCD System Top Vacuum Cleaning PCB Depaneling Router is suitable for various applications in the PCB manufacturing industry, including:
PCB Depaneling Router Machine Packaging:
PCB Depaneling Router FAQ:
1.A: What is life time of routing bit?
Q:150-300 meters.
2.A: Can this model cut Aluminum PCB boards?
Q: Yes, it can.
3.A: What about PCB positioning?
Q: Use customized jig for positioning.
4.A:What is the spindle for the inline PCB router?
Q:Germany SycoTec 4025.
5.A:How to package it?
Q:Router and cleaner is packaged into separated wooden case after vacuum.
6.A:Is on-site installation and training available.
Q:Yes, it is available.
7.A:What is your terms of delivery?
Q:We accept ex-work, FOB, CIF, DDU, DDP, etc.
