Product Details:
|
| Color: | White | Working Area: | 400x300mm |
|---|---|---|---|
| Output: | 8/10/15T/20T | PCB Thickness: | 0.08-3.5mm |
| Punching Fixture: | Die Tooling | PCB Material: | CEM, FR4, MCPCB |
| Cycle Time: | 7-15 Seconds | Name: | PCB Punching Machine |
| High Light: | 15T PCB Punching Machine,PCB Punching Machine For LED,15T FPC Punching |
||
15T FPC PCB Punching Machine for Aluminium PCB Boards For LED Industry Manufacturing
PCB Punching Machine Specification:
| Working area | 400*300mm |
| Working pressure | 0.45-0.7Mpa |
| Cutting precision | ±0.05mm |
| Cycle time | 7-15 seconds |
| Output | 8T |
| PCB/FPC thickness | 0.08-3.5MM |
| PCB/FPC material | FPC, FR1, FR4, CEM-1, CEM-3, MCPCB |
| Cutting mode | Punching |
| Punch fixture | Die tooling(mold) |
| Working Property |
LCD display, Automatically records the number of processed products, automatic punching |
| Transmission port | International standard |
| Operation Language | English |
| Stroke | 50MM |
| Mold height | 170MM |
| Power | 380/220V |
| Fuse | 3A |
| Machine dimension | 820x740x1750mm |
| Machine weight | 580kgs |
PCB Punching Machine Features:
1. Depaneling PCB/FPC by means of punching dies, to avoid micro-cracks caused by manual
2. Die toolings is changeable
3. Easy set up of punching dies
4. Loading and unloading PCBs is convenient
5. Easy operation, has safe protection system
6. Air cylinder driven
PCB Punching Machine Details:
PCB Punching Machine FAQ:
PCB Punching Machine Packaging:
1. Fix the machine base on the wooden base by screws
2. Vacuum
3. Lock the wooden case
PCB Punching Machine Delivery Terms:
1. Ex-work/FOB/CIF/DDU, up to clients
2. Production leadtime: 7-15 days to customized make die tooling and test it with the punching machine
Our Service:
1. Lifetime technical support and 2 years warranty.
2. Free replacement or refund would be done in case of any quality problem.
3. Fast response/feedback within 12 hours
4. Engineers are available to be sent to do oversea installation and training.
5. Solid packaging to prevent damage from transportation.
