Product Details:
|
| Pcb Thickness: | 0.5~3mm | Name: | Auttomatic PCB Board Separator |
|---|---|---|---|
| Speed: | 80-300mm/second | Condition: | Original New |
| Power Supply: | 110-220v | ||
| High Light: | CEM PCB Separator Machine,300mm/S PCB Separator Machine,Laser Cutting Solution PCB Depaneling Machine |
||
Automatic PCB Board Separator Machine PCB Board Cutter For LED Metal Board
It is widely used in modern PCB industry.
We offer the widest selection of depaneing machines for pre-scored and routed boards, including punching, routing, v-groove cutting
and laser cutting solutions.
V-Cut PCB Separator Features:
Pneumatic driven, electric hybrid design, double straight knife cutting, sutiable for dividing precision SMD sheet, aluminum circuit board.
Suitable for all thickness PCB, cutting board stroke is less than 2mm, no operational safety concerns.
Reduce the internal stress generated when cutting the board to below 180μST to avoid tin cracking and prevent damage to precision parts.
Cut the edge of the V groove and the width of the part is 0.3mm, the height is 50mm.
Blades can be re-sharpened
Cutting stress is less than 500 uE.
V-Cut PCB Separator Specification:
| Model | SMTPD2 |
| Machine Dimension | 720x300x440mm |
| Max Cutting Length | 330mm |
| PCB Material | FR4, MCPCB, CEM, Copper Boards |
| Air Pressure | 0.4-0.7MPa |
| PCB Thickness | 0.3-3.5mm |
| Power | 110/220V |
| Machine Weight | 130kgs |
V-Cut PCB Separator Details:
