PCB Punching Machine Sliding Bottom Mold

PCB Punching Machine Sliding Bottom Mold
PCB Punching Machine Sliding Bottom Mold PCB Punching Machine Sliding Bottom Mold

Large Image :  PCB Punching Machine Sliding Bottom Mold

Product Details:
Place of Origin: China
Brand Name: Winsamrt
Certification: CE
Model Number: SMTP300
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD1-10000/set
Packaging Details: Plywood case
Delivery Time: 7-15 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100 sets

PCB Punching Machine Sliding Bottom Mold

Description
Power: 220V Working Area: 460x320mm
Output: 25T Application: FPC, FR4, MCPCB
Precision: ±0.05mm Name: Aluminum PCB Punching Machine
High Light:

Aluminum PCB Punching Machine

,

Sliding Bottom Mold PCB Punching Machine

,

CEM PCB Punching Tool

Flex PCB Punching Machine FPC Punch With Customized Punching Dies



PCB Punching Machine Overview:

Double switch start operation.

Device configuration mode and out of the chute,and out of the lower mold automatic pick and place convenient and safe products.

Emergency stop switch,identify problems and timely shutdown.

Security doors,installation and commissioning of the mold to avoid straying hands.(Normal operation with out security door doesnot work).

Safety pressure setting function,limit alarm.Automatic counting,limit down time.

The internal stress generated when the cutting board to a minimum and to avoid cracking of tin.

Suitable for high volume routed boards.



PCB Punching Machine Specification:



Working area 460*320mm
Working pressure 0.45-0.7Mpa
Cutting precision ±0.05mm
Cycle time 7-15 seconds
Output 8T
PCB/FPC thickness 0.08-3.5MM
PCB/FPC material FPC, FR1, FR4, CEM-1, CEM-3, MCPCB
Cutting mode Punching
Punch fixture Die tooling(mold)
Working Property

LCD display, Automatically records the number of

processed products, automatic punching

Transmission port International standard
Operation Language English
Stroke 50MM
Mold height 170MM
Power 380/220V
Fuse 3A
Machine dimension 820x740x1750mm
Machine weight 580kgs



PCB Punching Machine Die Tooling:

PCB Punching Machine Sliding Bottom Mold 0PCB Punching Machine Sliding Bottom Mold 1PCB Punching Machine Sliding Bottom Mold 2



PCB Punching Machine Delivery Terms:

1. Ex-work/FOB/CIF/DDU, up to clients

2. Production leadtime: 7-15 days to customized make die tooling and test it with the punching machine.
