Winsmart Aluminum 400mm Motorized PCB Depaneling Cutter Machine

Winsmart Aluminum 400mm Motorized PCB Depaneling Cutter Machine
Winsmart Aluminum 400mm Motorized PCB Depaneling Cutter Machine Winsmart Aluminum 400mm Motorized PCB Depaneling Cutter Machine

Large Image :  Winsmart Aluminum 400mm Motorized PCB Depaneling Cutter Machine

Product Details:
Place of Origin: China
Brand Name: Winsmart
Certification: CE
Model Number: SMTAD5
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD1-10000/set
Packaging Details: Plywood case
Delivery Time: 2-5 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 200 sets per month

Winsmart Aluminum 400mm Motorized PCB Depaneling Cutter Machine

Description
Mode: Automatic Driven: Motor
Cutting Length: 450mm Cutting Speed: 100-500mm/s
Power: 50W Name: PCB Depaneling Cutter Machine
Highlight:

Motorized Pcb Depaneling Cutter

,

Winsmart Pcb Depaneling Cutter

,

Pcb Depaneling Cutter For Aluminum

Winsmart Aluminum 400mm Motorized PCB Depaneling Cutter Machine





Motorized PCB Depaneling Cutter Machine Function:

Widely used in the Manufacturing Machinery Electronic Products Machinery industry.



Motorized PCB Depaneler Features:

Round and linear knives to reduce stress during cutting.
Locking guide.

Linear bearing mechanism to align blades automatically.

Adjustable work table.

Safety guides.

Automatic parallel blade adjustment

Wide table on both sides of knives 158x508mm

Cut board with components overhanging scoreline with modified linear knife.



Motorized PCB Depaneler Specification:

Model SMTAD5
Machine Dimension L940*W550*H460 mm
Max Cutting Length 450mm
PCB Material FR4, MCPCB
Cutting Speed 300mm/s or 500mm/s
PCB Thickness 0.6-2.0mm
Power 220/110V
Machine Weight 85kgs
Wooden Case Dimension 100x67x62cm
Gross Weight 90kgs



Motorized PCB Depaneler Display:

Winsmart Aluminum 400mm Motorized PCB Depaneling Cutter Machine 0



Our Advantages:

Our machine is completed with fine finishing in accordance with the quality standards of the industry.
Our strict quality management system maintains the excellent performance and quality of our products.
The product is the preferred one in the fields for its huge economic benefits.
